使用用途与简绍/Brief Introduction：

机用户型利用非常特殊三通接头装灌阀，不适使用在水剂和膏霜类服务的装灌，很对高黏度原材料（如浓酱、尖椒酱、番茄酱、种衣剂、微乳剂、悬浮按钮剂等）的的效果非常显眼，且要求高。机用户型利用PLC可编写程序有效控制，和6厘米接触屏组队接口系統，全面推行半重新化进瓶，半重新化装灌，半重新化出瓶，电器产品，手动元机件均利用亚太加盟品牌，有效保障了不错的品质和经久稳固的耐腐蚀性。本机械机械设备构造简单，操控便于，是中国内地很好的针对性高黏度原材料的装灌机械机械设备。机用户型配发了阻止滴漏问题问题与不锈钢压模的装灌闷头，有效保障装灌结束以后后无滴漏问题问题，无不锈钢压模。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优势特点/Characteristic：

◆掌握模式——用三凌PLC掌握模式，灌装线摄入量自由调准。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆实操表面——64英寸彩屏手触式实操表面，精确性十分简单、安全性高可信度Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆性能改变——上下料有防漏滴提升装置，可会按照原料基本特征兼具下潜包装性能。（此性能可能使用的）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电子产品元器件——均主要包括国际性老牌企业品牌，确认机械设备的安全性准确无误、准确无误性强；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆厂家主件——广州POS机主件均利用优质的304不锈碳钢作,深表歉意须要触碰材料能能利用316L另缴费用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆筛选查重——雷达回波图筛选，对运转总产值抽象概念投诉。Counting test, real-time, intuitive reflect the yield of work.◆装灌加测——无瓶不灌、瓶数不是很不灌Bottle filling test - no bottle no filling, not enough◆运维症状——该设备合乎GMP标准，可高效拆下来、清洁工作运维。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆改换要求参数——替换灌装设备要求参数时，只需要简单易行调整，便捷追到。Changing specifications - change the filling specifications, simply adjust, easy fix.◆绿色绿色节能减排安装——安装了绿色绿色节能减排的框架，使器机的运营氛围更有整洁卫生情况。（此绿色绿色节能减排安装就可以选购）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

水平性能参数/technical parameters：

罐装头数The number of filling head	8头（可以选择4、6、8、10、1多个分装头）8 head (optioꦺnal 4, 6, 8, 10, 12 ♋filling head)
适宜瓶径 Applicable bottles Drive	Ф33-Ф100 mm
收费准确度measure precision	±1%
罐装余量Canned capacity	150-1000ml
生产的性能Production Capacity	2400-4000瓶/一小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
